抗UV防水按键开关
所属分类：12mm防水按钮开关
- 点击次数：
- 发布日期：2024/03/03
- 在线询价
详细介绍
抗UV按键开关，光面防水按键开关,室外专用防水按键开关
大电流小型防水按键开关，直流电防水按钮开关,低温环境使用的按钮开关，高寿命防水按键开关，汽车防水按键开关。
ELECTRICAL RATING:
ELECTRICAL RATING:
Resistive: 28VDC 5A 4A(DB) 25,000cycles
Resistive: 115VAC 1A 1A(DB) 25,000cycles
Inductive: 28VDC 2A 2A(DB) 25,000cycles
Contact Resistance: 50mΩ Max.
Insulation Resistance: 1GΩ @ 500DVC
Dielectric Strength:AC 1000V 1 minute
Mechanical Life:1,000,000cycles
Operating Temperation:-40°C~+85°C
Switch action: Momentray
Switch circuitry: SPDT-DB ,load 1N.O./1N.C. 2 Circuit Life
Actuator Ingress Protection: IP67,IP68S,and IP69K (Front Panel).
Total traver: 1.6mm max.
Operating Force :1.7lbs [770g]. Release Force :12oz [340g]
Stands: UL61058 ROHS
