IP68带灯线上防水开关
所属分类:IP68线上按键开关
- 点击次数:
- 发布日期:2024/12/06
- 在线询价
三色灯线上开关,IP68防尘防水按键开关,防水线上开关 线上防水开关,防水线上开关,防水带线按键开关
Waterproof Pushbutton Switches
SAFETY/QUALITY APPROVALS
SGS/REACH/IP68
SPECIFICATIONS
Contact Rating: 50mA 12VDC
Mechanical Life: Momentary 100,000 cycles Self-lock 50,000 cycles
Electrical Life: 50,000 cycles make-and-break cycles.
Travel: About 2.0mm
Operation Pressure: About 8N
Contact Resistance: 50 mΩ max.
Insulation Resistance: 100MΩ min.
Dielectric Strength: 500 Vrms @sea level.
Operating Temperature: -20°C to 85°C
Ingress Protection: IP68
RoHS
MATERIALS
Bushing : PA66
Base : PBT/PA66
Actuator : PA66
Inner Assembly: POM / Sillicone.
Spring : Spring steel.
Sealing: Sillicone.
O-Ring : Sillicone
Led: 1.8V/3V/6V/12V/24V/36V/48V/110V/220V
ILLUMINATION BASE RATlNG:
Red, Yellow and Orange:20mA 1.8V;
Blue, Green and White:20mA 2.8V
Beads Color:R/U/G/Y/0/W
产品应用:便携式工具和机床、测验设备、售货机及饮水设备、户外防水设备
烧烤炉及商用厨房设备、公共交通控制、白色家电、通信设备、医疗设备、电动车行业
计算机机箱、安防及门禁系统、警报设备和安全系统、数据录入设备、自动化设备、仪器仪表
汽车轨道交通、酒店设备、照明灯具、电动玩具、电网电力系统、美容器材、音响视频设备、机器人
食品加工设备、运输起重装置、办公设备、3D打印设备
